About us
ViscoTec is a leading German manufacturer which offer high-precision dispensing pumps and systems worldwide over 27 years with special on dosing technology for medium and high viscosity fluids and pastes.We supplies advanced technology of fluid dispensing solutions to support the development of China market with made-in Germany quality. Our dosing systems and components are required for conveying, dosing, dispensing, filling as well as for emptying and treating of fluids and pastes. They function regardless of viscosity: For all materials with a viscosity of up to 7,000,000 mPas. Handling is pulsation-free and particularly low-shear.
ViscoTec provides comprehensive consultant and customized solutions for each application requirement for our customers. Our high-quality products are used in a wide variety of industries such as e-mobility, aerospace, electronics, food, biochemistry, pharmaceuticals, cosmetics, and medical technology.
Address
Amperstr. 13
84513 Töging a. Inn
Germany
E-mail: sales@viscotec-china.com
Phone: +49 8631 9274-0
Internet: www.viscotec.com.cn
BLK 16, City of Elite. No. 1000 Jin Hai Road, Pudong
201206 Shanghai
China
E-mail: sales@viscotec-china.com
Phone: +86 21 61659002
Internet: www.viscotec.com.cn
Products & Services
vipro-PUMP: 1-component Dispenser
Dosing volume: ~0.14 ml/U bis ~5.2 ml/rev
Volume flow: ~17 bis 650 ml/min (1)
Min. dosing volume: 0.01 ml (2)
Optional: With hard chrome plated standard rotor or optional with ceramic rotor for highly abrasive materials
(1) Depends on the mixing ratio and the viscosity of the dosing material.
(2) Depends on dosing material, viscosity, pre-pressure and mixing ratio.
-thumb.webp)
preeflow®eco-DUOMIX
eco-DUOMIX precision volume dispensing unit made by preeflow enables mixing and dosing of the smallest quantities of 2-component fluids and pastes.The dead space optimized mixing capsule used, instead of a mixing spiral, is available as a consumable and is installed directly at the outlet of the dispenser.Precise application of even the smallest sealing beads is achieved by means of an exchangeable dosing needle, which is mechanically connected to the mixing capsule.
-thumb.webp)
preeflow® eco-PEN XS 180 microdispenser
eco-PEN XS 180 is a high precision volumetric micro dispenser designed for dispensing extremely small quantities of materials with varying viscosities. It excels in applications requiring precise metering, making it suitable for electronics manufacturing, medical technology, and other industries with high precision requirements. This dispenser features a rotating, pressure-sealed displacement system that ensures consistent and reliable dosing without altering the dispensed material. It can handle various viscosities and dispense amounts in the nanoliter and microliter range.
vipro-DUO：2-component Dispenser
vipro-DUO is a new 2-component dispenser designed for the precise dispensing of materials with different viscosities. It combines the best features of the vipro-PUMP and the mature ViscoDUO technology, providing modularity and flexibility. Here are its main features:
ModularDesign: Each side is equipped with five different dispenser sizes, with mixing ratios ranging from 1:1 to 100:1.
Optimized Mixing Block: Ensures materials are handled gently during processing, maintaining consistent density during dispensing.
Reduced Installation Bracket: Optimizes installation space, facilitating integration with automation applications.
Dual Outlet: Ensures reliable ventilation of the mixing block.
Front-Mounted Metering Pressure Sensor:Used for process monitoring and easy calibration.
Progressive Chamber Technology: Ensures precise metering and long product life even with high filler content.
